Kearney & trecker lead attachments operators manual
This is a reproduction, not a photocopy, of an original Kearney & Trecker Milwaukee Table of Lead and Indexing Divisions for Model K Universal Dividing Head and Conventional and Low Lead Attachments with US standard lead screw. This manual contains operating instructions and all the lead charts for these attachments. Please see index below.
I INTRODUCTION...................................4
II MODEL K UNIVERSAL SPIRAL DIVIDING HEAD
Spindle........................................4
Index Crank and Plunger........................5
Hand Drive.....................................5
Tail Stock.....................................5
Steady Rest....................................5
Right Angle Drive Bracket......................5
Index Plates...................................5
Lubrication....................................6
Astronomical Divider...........................6
III CONVENTIONAL LEAD ATTACHMENT...................6
IV LOW LEAD ATTACHMENT............................8
1. Model K Universal Spiral Dividing Head and
Conventional Lead Attachment...................3
2. Model K Universal Spiral Dividing Head and
Low Lead Attachment............................3
3. Schematic Drawing..............................4
4. Right Angle Drive Bracket......................5
5. Astronomical Divider...........................6
6. Gearing in Conventional Lead Attachment........7
7. Idler Gears in Conventional Lead Attachment....7
8. Mounting Low Lead Attachment...................8
9. Gearing in Low Lead Attachment.................8
1. Plain Indexing - Model K Universal Spiral
Dividing Head Using Standard or High
Number Index Plates........................10-13
2. Leads - Conventional Lead Attachment.......14-23
3. Leads - Low Lead Attachment................24-39
4. Thread Milling.............................40-44
