Therm-o-type 475M 12" floor model thermography machine


* Manufacturer: Therm-O-Type
* 475M Thermography Machine
* Ultraviolet Curing System
* Condition: Working very well. Fully operational, uninstalled from working print shop just 3 weeks ago. This machine has an Ultraviolet Curing System included which is a great feature on a machine like this!
* The Therm-O-Type 475 has been specifically designed to meet the needs of professional thermographers. It features heavy duty construction, precise operator controls, energy efficiency, enhanced mechanical and electrical safety features, high productivity and durability. Maintenance requirements have been minimized to reduce unproductive down time.
* The heavily insulated 37" long heat tunnel provides excellent dwell and 9,500 watts of heat. Dual tracking heat control assures precise temperature control while protecting the heater elements from stress. Delivery end heater height can be adjusted as required.
* The machine is mounted on 4 heavy-duty casters that allow for excellent mobility, requiring zero dedicated floor space!
* Equipped with top and bottom heaters to prevent paper curling issues commonly found on units with top only heaters.
* Two full width heating zones.
* Unit is built for the retail thermographic industry.
* Built for the raise printing for business card production.
* Maximum paper width of 12" wide.
* Ultraviolet Curing System:
* 11" @ 300 watts per inch output, Ozone free lamp.
* Floor mounted, encased power supply
* Full/Half power lamp control
* Elapsed time indicator
* Secondary lamp ammeter
* High voltage key locked cable from power supply to lamp assembly
* Mercury vapor ballast/capacitors
* 220 volts/60 hz, 30 amps main power supply required
* Maximum Production Speed: 8,000 inches per hour (tested on 8.5" x 11" 60# cover stock)
* Length: 168" (not including feed conveyor)
