Leica MZ6 stereomicroscope di SMS6B boom stand 10X/21B
Leica MZ6 Stereomicroscope w/DI SMS6B Boom Stand
Leica MZ6 Modular Stereomicroscope with10x/21B Optics
Diagnostic Instruments SMS6B Light Duty Ball Bearing Boom Stand
The Leica MZ6 modular stereo microscope with with 10x/21B Optics can accommodate a large range of accessories for customization such as the optional fluorescence ring light, which allows homogeneous reflex free illumination or the mountable focus arm for the swing arm stand, which is ideal for saving space when inspecting a wide range of samples for a variety of life science and industrial applications. The Scope has a 1.0x shield on the bottom.
The Leica MZ6 designed with 7-position ratchet stop enables repetitive inspection and measurements at a specific zoom position.
7-position ratchet stop allows quick, easy, reproducible inspection and measurement at specific zoom range, which reduces errors.
Mountable focus arms for swing arm stands Less workspace needed, which is ideal for inspecting a wide range samples.
15 different main objective options achromatic, planachromatic or planapochromatic objectives available for the user to customize the instrument for specific application requirements.
Manual: http:// /products/stereo-microscopes-macroscopes/routine-manual/details/product/leica-mz6/downloads/
* Linear ball bearing support of dual shaft horizontal arm creates smooth, gliding movement
* Adjustable lever handles and "Soft-Grip" knobs for your convenience
* Moderate price for many of the same features found on the most expensive stands available
The SMS6B stand was designed for people who are using the smaller stereo microscopes for inspection work and want a boom stand that gives a smooth horizontal arm movement.
Combining the best of both worlds, the SMS6B has a ball bearing supported dual shaft horizontal arm that allows it to move smoothly with none of the "slip-stick" that is common with bushing supported horizontal arms. Ball bearing guides are used on both shafts for extra smooth operation. The SMS6B needs no adapter if your microscope focus mount has the industry standard 5/8" "Bonder Mount".
The 5/8" diameter dowel on a "Bonder Mount" fits into a vertical socket in the end of the horizontal arm. A lever knob adjusts a friction collar that traps the bonder dowel and allows the microscope to rotate around a vertical axis. This allows the microscope to be aligned with the users eyes when repositioned.
Tilting and non-tilting adapters are available for microscopes that do not have the 5/8" diameter microscope mounting dowel.
This item comes with a 3 day right of return policy.
All returns must be made within 3 days of receipt.
All warranties are void if the calibration / warranty seals are broken.
Ascent Concepts and Technologies is a Research & Development Lab. As a service to the companies and institutions we work with, we broker their excess equipment & act as application specialists on their new equipment needs. We are now offering quality used equipment to the public with the same level of professionalism and service.
