1.25" dia. pines 5T pipe bender
1.25" Dia. Pines 5T PIPE BENDER
1-1/4" PINES Hydraulic Rotary Pipe Bender
Non-Ferrous Tubing Y.P. to 25,000 PSI: (2) 1" O.D. x .072" Wall,
Mild Steel Tubing Y.P. to 40,000 PSI: (2) 1" O.D. x .065" Wall,
Stainless Steel Tubing Y.P. to 60,000 PSI: (2) 1" O.D. x .049" Wall,
Steel Pipe Schedule 80: (2) 3/8",
Square Tube (Mild Steel): (2)7/8" x .035",
Round Bar (Mild Steel): (2) 5/8",
Square Bar (Mild Steel): (2) 1/2",
Tube Size Range Up to 1-1/4" or (2) @ 1",
Centerline Radius Range: (Permitting Bending to Maximum Angle)
3-1/2" Maximum C.L.R., 2" - 3" Minimum Work Diameter,
Bend Angle: 140 Degrees Maximum, 165 Degrees with Special Tooling,
Production Speed 2,000 Bends Per Hour,
Heavy Cast Steel C-Frame Type Construction,
Pedestal Mounted Push Button Operation,
Dimensions, Approx. 64" L-R x 87" F-B x 60" H
