Tektronix 7B52 plug in instruction manual
Tektronix instruction manual for the 7B52 Dual Time Base plug in unit. Manual contains Specifications, Operating Instructions, Circuit Description, Maintenance, Performance Check/Calibration, Electrical Parts List, Diagrams (includes schematics and troubleshooting information), and Mechanical parts list. The book s spiral back has several fingers missing, but all pages are present and accounted for. The manual is in very good condition. Tektronix part number 070-1043-00. I will try to answer any questions you might have. Email me if you need.
