Yaesu sp-8 speaker
I bought this speaker from Universal Radio about two years ago to match my Yaesu FT-1000MP (also for sale in another listing). The speaker works great, I never have had any problems with it nor has it been modified in any way. It has been used in a non smoking environment. Looks great- the face is flawless. there was some very minor scrapes on the sides. The only reason I am selling it is that life priorities have changed and I no longer have time for radio and along with that, I need to sell off some under utilized gear.
Description From the Universal Radio website:
The Yaesu SP-8 is a base speaker with audio filtering. It features both a 1/4 inch headphone jack and a 3.5 mini jack on the front panel. Input A or B or may be selected by a push button switch on the front panel. The panel also has a 4 position MODE switch: Mute, Manual, SSB, CW. There is a 3 position Low Cut Filter knob and 4 position High Cut Filter knob.
The rear panel features Input Jack A and Input Jack B. There is also a Line Out Jack. All three of these jacks are RCA Phono type. The speaker comes with one audio cable (RCA to 3.5mm mini). The SP-8 also has adjustable front feet. This will allow you to angle the speaker up.
LOW 1 below 300 Hz (-6 dB/oct)
LOW 2 below 600 Hz (-6 dB/oct)
HIGH 1 above 2.4 kHz (-6 dB/oct)
HIGH 2 above 1.1 kHz (-6 dB/oct)
HIGH 1 above 700 Hz (-6 dB/oct)
SSB above 2.4 kHz (low pass filter)
Size 7.8 x 5.3 x 12 inches (200x135x305 mm)
SP-8 Universal Radio website description Link:
http:// /CATALOG/speakers/1789.html
http://www.eham.net/reviews/detail/401
