Pcb dip switch: lot of 50 pcs 7 position 14 pin spst
PCB DIP Switch: Lot of 50 pcs 7 Position 14 Pin SPST
Contact rating(Switching):25mA 24V DC
Contact rating(Non-Switching): 100mA
Contact resistance (initial): 50mO Max
Contact resistance(after life test): 100mO Max
Insulation resistance: 1000MO Min. at 500V DC
Dielectric strength: 500V DC Min. for 60 seconds. 1mA
Capacitance between adjacent switches 5PF Max
Operating Temperature: -25 to 70 degree Celsius
Storage Temperature: -40 to 85 degree Celsius
Mechanical life: 2000 operations
Humidity: 95%RH, 40 degree Celsius for 96Hrs
Solderability: After flux: 230 5 degree Celsius for 5 0.5seconds,95% coverage
Resistance to soldering heat: 260 5 degree Celsius for 5 1seconds
* Packaging: IC tube with all the pole in OFF position
* Part. No.: HAD-07H(07L)W-R
* Postage for this item is $5.00
