Skyjack sjiii 4632 scissor lift manlift aerial platform
Skyjack SJIII4632 Electric Scissor Lift Inspected and Work Ready
Serviced and Inspected by our Skyjack trained mechanics
Raised Platform Height 32 (9.8 m)
Lowered Platform Height 48.5 (1.2 m)
Stowed Height (Rails Up) 88 (2.2 m)
Stowed Height (Rails Down) 74 (1.9 m)
Platform Width (Inside Dimension) 42 (1.1 m)
Platform Length (Inside Dimension) 84 (2.1 m)
Extension Deck (Roll Out) 4 (1.2 m)
Ground Clearance (Stowed) 3.5 (8.9 cm)
Ground Clearance (raised) 0.75 (1.9 cm)
Turning Radius (Inside) 47.5 (1.2 m)
Turning Radius (Outside) 93.5 (2.4 m)
Lift Time (With Rated Load) 59 sec
Drive Speed (Stowed) 2 mph (3.2 km/h)
Drive Speed (Raised) 0.6 mph (1 km/h)
Maximum Drive Height Full Height
Capacity (Overall) 700 lbs (318 kg)
Variable speed, rear two wheel hydraulic drive
Proportional controls for drive & lift functions
4 (1.2 m) roll out extension deck
Low voltage battery protection
Color coded and numbered wiring system
Solid rubber, non-marking tires
110V AC outlet on platform with GFI
Tilt alarm with drive & lift cut-out
Hinged railing system (except 4620)
Forklift pockets and tie down/lift lugs
OVER 1300 MACHINES AVAILABLE FULLY SERVICED AND WORK READY!
For Add'l Information Regarding This Lift, Please Call Dean (630)514.9449
