Tektronix 577/D2 non storage curve tracer
Tektronix 577/D2 Non Storage Curve Tracer
Provides for low current measurements with storage display capabilities
Allows characteristic curves of two devices to be overlaid
Collector supply (five modes, five ranges) provides 6.5 V/10 A, 25 V/2.5 A, 100 V/0.6 A, 400 V/0.15 A, and 1600 V/0.04 A
D2 = Non-Storage Curve-Tracer Mainframe (without test fixture)
