Compsee apex ii portable data terminal w/ barcode
Compsee Apex II Portable Data Terminal W/ Barcode
I am selling one Compsee Apex II Portable Data Collection Terminal. The price for these new was $1695.00/Ea. If you need more than the number available please email us with quantity needed.
This item has been tested and is in working condition. I have downloaded the latest operating system and Apex-Track software fom the Manufacturer's Web Site to it and read several different types of barcodes.
Below is some more information and a link to the manufacturers web site.
http:// /Products/apex2.htm
Display LCD - 4-line x 16-character Memory 128K to 1MB RAM, 512K flash Clock Real-time clock calendar
Time and date Stamping via software Communications Port RS 232 interface
Protocol - XON/XOFF, CTS/RTS
Baud Rate - Programmable 300 to 19,200 Indicators Programmable audible beeper Keyboard Full alphanumeric, 49-key Software Programmable in BASIC
Program Generator Microprocessor 16-bit, Intel 80196NP
Power Source Four AA alkaline batteries
Four AA NiMH or NiCd batteries
Rechargeable NiMH pack Battery Pack Life 15 hours at use rate of 30 scans/minute Back-up Battery Super Cap
Operating Temperature -4 to +122 F (-20 to +50 C) Storage Temperature -4 to +140 F (-20 to +60 C) Humidity 90% relative (non-condensing) ESD 15 KV electrostatic air discharge
to all surfaces without the loss of
data. Meets IEC 801-2(1991) Construction Industrial high-strength polycarbonate
Chemical and splash resistant Drop Unit Functions normally after 4' (1.2m)
drop to concrete Regulatory Agency Approval FCC Part 15, Class A: CE
Weight .934 lbs. Size (LxWxD) 8.4" x 3.8" x 2.1"
Laser Diode 680 nm Scan Rate 36 scans/second (bi-directional) Skew +/-65 Pitch +/-55 Specular Dead Zone +/-2 Ambient Light Immunity Immune to direct exposure from normal
office and factory level lighting
and direct exposure to sunlight Contrast Ratio 20% absolute dark/light reflectance
differential at 675 nm. Bar Code Symbologies Code 3 of 9 (Standard & Full ASCII)
UPC/EAN/JAN + addendums
Codabar Code 11
Interleaved 2 of 5 Code 128
MSI/Plessey Code 93
Standard 2 of 5 Matrix 2 of 5 Optional Bar Code Scanner Tethered- Light Pen, Laser or CCD
Integrated- Standard or Long Range Laser
Item can be picked up in Houston at no charge. Texas residents must pay 8.25% sales tax.
