Ames a-200 a-1700 a-2300 bench lathe parts manual
This is a reproduction, not a photocopy, of an original Ames Enclosed Head Bench Lathe Parts Manual. This manual contains parts diagrams for the A-200 headstock with 1" capacity, the A-2300 compound slide rest, and the A-1700 tailstock. There are also a couple of pages on accessories for the headstock and tailstock. The lathe was originally covered in three different manuals. I've collected all the different manuals and combined them together here. The manuals are hard to come by in a full set, and there weren't a lot of these lathes made.
