New jet 22-44 pro 3HP, 1PH sander w/ dro 649600
JET 22-44 Pro 3HP, 1Ph Sander With DRO
* 22" wide suspended drum is supported on both ends with a truss-like carriage arm for greater strength and easy alignment to the table surface for consistent performance
Motor 3 HP; 1 Ph 230V; Pre-wired 230V Drum Speed 1,600 RPM Maximum Board Thickness 4" Conveyor Speed 0 to 10 SFPM Amps 8 Amps Conveyor Motor yes Net Weight 385 lbs. Drum Dimensions 5-in x 22-in Minimum Board Length 2-1/4-in Minimum Board Thickness 1/32-in Maximum Board Width 44-in (2 passes) Dust Port Diameter (OD) 4-in Overall Dimensions 41-in x 41-in x 52-in
* 22-44 Pro 3HP, 1Ph Sander with DRO - 649600
