> 56" tbl 5HP spdl cincinnati cinel 60 #205-12 universal
56" tbl 5HP spdl cincinnati cinel 60 #205-12 universal
56" Tbl 5HP Spdl Cincinnati Cinel 60 #205-12 UNIVERSAL
56" Table 5HP Spindle Cincinnati Cinel 60 #205-12 UNIVERSAL MILL, #50 Taper Hor/#40 Taper Vert,Table
MODEL: CINEL 60 205-12,S/N: 31032U5W-3, NEW: 1970
TABLE WORKING SURFACE ................ 12" x 54-1/2"
T-SLOTS NUMBER & SIZE ................ (3) 11/16"
DISTANCE BETWEEN T-SLOTS ............. 2-1/4"
LONGITUDINAL TABLE TRAVEL (X)......... 28"
SADDLE TRAVEL (Y) .................... 10"
KNEE TRAVEL (Z) ...................... 16"
TABLE SWIVEL LEFT & RIGHT ............ 45 DEGREES
LONGITUDINAL & CROSS ........... 1/4 - 30 IPM
VERTICAL ....................... 1/8 - 15 IPM
LONGITUDINAL & CROSS ........... 150 IPM
VERTICAL ....................... 75 IPM
NOSE ........................... #50 STD
SPEEDS (16) .................... 25 - 1,500 RPM
SPINDLE NOSE ................... #40 STD.
SPINDLE QUILL TRAVEL ........... 5"
SPINDLE SPPEDS VARIABLE TWO RANGES:
LOW RANGE .................... 85 - 535 RPM
HIGH RANGE ................... 615 - 3,800 RPM
SPINDLE FEEDS(3) ............... .015, .003 & .006 IPR
DIMENSIONS ........................... 78" x 70" x 75"
- ACU-RITE ONE AXIS DIGITAL READOUT
- 2 HORSE POWER VERTICAL HEAD MOTOR
- 5 HORSE POWER HORIZONTAL SPINDLE MOTOR
