> New raychem SMD100-2 polyswitch resettable fuse, , 10PCS
New raychem SMD100-2 polyswitch resettable fuse, , 10PCS
This Lot (Qty.10) is New Raychem Polyswitch SMD Resettable Fuse, Part Number: SMD100-2. The device allow the circuit to open when exceed certain current in order to protect the circuit. It will reset to normal when current is normal.
* Maximum Hold Current: 1.1A
* Minimum Trip Current: 2.2A
* Maximum Current Without Damage: 40A
* Maximum Power Dissipation: 1.7W
* Initial Resistance: 0.12 Ohm min. to 0.24 Ohm max.
* Operating temp: -40C to +85C
* No Manual Resetting or Replacement
http://datasheet.digchip.com/000/000-0-SMD030-2.pdf
