Plc 24 i/o, 85-265VAC, including cable and dongle
PLC 16 Digital inputs and 8 relay outputs. Operating supply voltage requirement 85 to 265
The kit includes all parts for connection to a computer, parts included are: 1 x K24PADRS, 1 x KLC-010 and KLA-009
Please download the programming software KGLWIN (compatible with VISTA and XP) from IMO website , you may have to register to access this facility.
* Program control method: Cyclic execution of stored program
* Applications instructions: 154
* Processing speed: 1.2 sec/step
* I/O relay: Up to 24 I/P 24 O/P
* Data registers: 256 words retentive
* Kinds of timers: On-delay, off-delay, accumulate, monostable, retriggerable
* Kind of counter: Up counter, down counter, up/down counter, ring counter
* High speed counter: 8Kpps, 24VDC, counting up to 4,294,967,295 1 point (1 or 2 phase)
* Computer link: RS232 (9600 bps) plus up to 32 CPUs linked via RS485 (300-19200 bps)
* Real-time clock (option): Setting and monitoring (seconds, minutes, hour, day, month and year)
* Rated input voltage: DC24V
* Rated output voltage: AC250V, DC30V
* Rated input current: 7 1mA/point
* Rated output load current: 2A/1 point
* ON-OFF output component: Relay
* Leakage current (output off condition): 0.1mA or lower
* OFF->ON response time, input and output: 10ms or lower
* ON->OFF response time, input and output: 10ms or lower 10ms or lower
* I/O indicator: LED display
* Dielectric withstand voltage: AC 1500V for 1 minute
* Noise resistance: 2000Vpp noise voltage, 1 s noise width
PLASE NOTE: ALTHOUGH THE PRODUCT IS NEW, THERE WILL BE NO WARRENTY
Download Full Datasheets from:
Part Reference: K24PA-DRS + KLC-010 +KLA-009
