Terminator I/O System Din DC Output Module T1K-16TD1
This is a Used T1K-16TD1 DC Output Module. This is the expandable module that, when attached to a base, creates an I/O System. Cosmetically, it is in good condition. No testing was done. The unit does not snap on as tight as it should but it is very stable mounted on the din rail. The photos are of the actual item for sale. Only what is shown is included.
* Outputs Per Module: 16 (Sink)
* Commons Per Module: 4 internally connected
* Operating Voltage Range: 6-27 VDC min./max.
* Output Voltage Range: 5-30 VDC min. / max.
* Max. Output Current: 1A / pt., 4A / common
* Max. Leakage Current: 15 A @ 30 VDC
* ON Voltage Drop: 0.3 VDC @ 1.0A
* Max. Inrush Current 2A for 100 ms
* OFF to ON Response: < 10 s
* ON to OFF Response: < 60 s
* Base Power Required: 200 mA @ 5 VDC
* External Power Required:400 mA max. @ 20-28 VDC
* Status Indicators: Logic side
* Error Status Indicators: 24 V ON = low external power/FU1/FU2 ON = fuse 1 or 2 blown FU3/FU4 ON = fuse 3 or 4 blown
* Fuses (User Replaceable): 4
