National optronics horizon 2 edger
The Horizon II is a time tested, dry-cutting pattern edger that can edge CR-39, Polycarbonate and Hi-Index lenses.
Speed,Accuracy and Convenience of Dry-Cutting Technology
Plastic debris is removed by a vacuum system, eliminating the need for coolants.
As factory equipped, the edger will cut bevel and rimless interchangeably. Optional cutters expand
edge peripheries to a dozen finishes, including Grooving, Faceting, Shelving and Roll & Bevel.
Standard cycle time is less than one minute, with a 20 second finish-only cycle for touch-up. Even the largest Poly lenses can be edged in a single cycle with a slower flow control cycle
Fully integrated circuitry eliminates microswitch adjustment, ensuring high reliability.
Thousands of installations worldwide have proven the Horizon II to be a workhorse of the industry.
Two fully-adjustable bevel guide systems are standard: A Teflon Guide Wheel which tracks the actual front curve of the lens or a Cam Tracking System which duplicates nominal base curves. Both
systems provide for fully variable front-to-back placement on all periphery finishes. Each system
features a cycle-pause feature which allows the operator to easily make bevel placement adjustment
Pattern from a lens capability, a feature unique to dry edging, is standard.
Our DC, brushless motor is ultra quiet and more durable than conventional router motors.
* Multiple edge finishes with optional cutters.
* Modular design facilitates in-lab maintenance and repair.
* Factory training and technical service support included.
80 PSI clean, dry compressed air required
ETL LISTED, Conforms to UL Std. for Electrical Equipment for Laboratory Use ETL TESTING
Standard cycle time is less than one minute, with a 20 second finish-only cycle for touch-up. Even the largest Poly lenses can be edged in a single cycle with a slower flow control cycle.
Front Base Curve Range: 0 -12D
Minimum Finished B Size::24mm (with 1/2-eye clamp:19mm)
