Omron C200H/C200HW-CLK21 plc cpu controller 3G2NL 24VDC
Omron C200H/C200HW-CLK21 PLC CPU Controller 3G2NL 24VDC
This is a used Omron PLC CPU Controller. This unit was pulled from an enclosure where it was part of a custom application. It is comprised of 3 modules mounted on a plate. The plastic coverings were removed from the modules (see photos), and are not included. The top module is an Omron #C200HW-CLK21 (without its cover), attached to a 3G2NL-CPU01 (which has one 9-pin serial female and one 20-pin male unknown port). The module below that is a 3G2NL-DRM21, and the module below that is a 3G2NL-SC001 (C20HB-MD213 board). The plate that the modules are mounted to reads: 3G2NL-SC003-HT CPU Unit (see photos). Everything we know about this unit has been stated here - please view photos to help answer any questions you may have.
This unit was pulled from a working system, however we do not have the means to properly retest it.
Cosmetically, it is in good condition with no major damage to any components.
