Hp 5345A/011 w 5356A & 5355A 18GHZ pulse freq counter
HP 5345A/011 w 5356A & 5355A 18GHz Pulse Freq Counter
Powers up, appears fully operational although not fully tested.
The Agilent 5345A universal counter is a high-performance microwave and millimeter-wave pulse frequency counter. Operating from dc to 500 MHz, the counter also makes sub-microwave measurements including frequency, period, totalization, ratio, and time interval. As a full universal counter, the 5345A features 2 ns single-shot timing resolution, improving to 2 ps with averaging.
* Output of more than 9000 measurements per second reduces test time
* Flexible external gating extends application
* Automatic averaging improves accuracy
* Frequency with resolution of 9 digits per second
* Option 011 = GPIB HP-IB Includes remote programming
The 5356A Frequency Converter provides pulse and CW frequency measurement capabilities to 18GHz.
* 100 Hz measurement resolution
* 75 nsec minimum pulse width
* 20 nsec minimum external gate
* CHIRP profile or VCO post-tuning drift
The 5355A Automatic Frequency Converter when used with a 5356A, 5356B, or 5356C Frequency Converter Head (sold separately), provides pulsed and CW frequency measurement capability to 18/26.5/40GHz for the 5345A Counter. 0.4 to 1.5GHz prescaled input offers pulsed and CW measurement for the lower microwave range even without one of the heads. This is all accomplished while utilizing the 5355A's internal microprocessor which controls the measurement algorithm, computes the input frequency and displays it on the 11-digit 5345A display (sold separately).
Approx Weight: 0 lbsBoxed Dim: 0x0x0 in
