New mks/hps 3X1.5" vacuum line heating system+extras
New MKS/HPS 3x1.5" Vacuum Line Heating System+Extras
This is a New MKS/HPS 48 Series Vaccum Line Heating System. The kit includes the Heating Jacket, Controller, Communications Module and Standard Tee. This assembly allows temperature to be controlled in industrial vacuum line systems. Cosmetically, the item is new and in flawless. The photos show a typical item. Only what is shown in the photos is included. This item does not include software or manuals.
* Weld Reducer Heater Jacket Size: 3"x1.5" 3.6" Length
* Pre-Set Temperature Set Points 150 C (302 F); or 105 C (221 F)
* Exterior Range Temperature Ambient to 85 C (185 F) (dependent on set point)
* Interior Range Temperature Ambient to 185 C (365 F)
* Foam Thickness: 0.5 in. (12.7 mm)
* Materials: Molded silicone foam, fiberglass reinforced silicone, Teflon insulated wire
* Connectors: Molex Mini-Fit Jr.
* Weight Range 0.5 to 6.2 lb (0.73 to 2.8 kg)
* Product Safety UL /C-UL Listed, CE,Semi S2
* Power Requirements 100-240VAC input
* Relay Contact Rating SPDT, 2 A @ 50 VAC resistive, 1 A @ 30 VDC
* Input/Output Wiring: 1 Thermal switch line IN/2 Thermal switch line OUT/3 Normally closed/4 Common/5 Normally Open
* Dimensions: Base Unit 3.5" x 2.2" x 1.6" (88.9 x 55.9 x 40.6 mm) w/ Mounting Bracket 3.5" x 2.2" x 1.9" (88.9 x 55.9 x 48.3 mm) w/ Upgrade & Bracket 3.5" x 2.2" x 2.5"
* Product Safety UL /C-UL Listed, CE, Semi S2
* 1 Heater Jacket Weld Reducer: 4830-0141
* 1 Base Controller: 4800-1150
* 1 Communications Module: 4800-0002
