Kt-2PRO DDR2 ram memory modules tester w/ pc & software
KT-2Pro DDR2 RAM Memory Modules Tester w/ PC & Software
This is a used King Tiger Technology Inc., KT-2 Pro DDR2 RAM Memory Module Tester + DELL Optiplex GX280 Computer. The tester and the computer are in good physical condition. Cosmetically, they both have several scratches on the exterior from normal use. We booted the computer up to the BIOS to record screen shots of its components. We started the Tiger Claw software and ran the self diagnostic option. All diagnostic tests passed. We also ran the Test Plan Wizard to test each DUT Module. The system was able to recognize different memory modules installed while running the Test Plan Wizard. No further testing was done. Only the existing software installed on the PC comes with this item. No Monitor, Keyboard, Mouse, software CDs, or Cables come with this item.
The KT-2Pro is the first low cost tester to reach speeds up to 800 MHz data rate for DDR2. Exercising the full memory array with true, at speed, Double Data Rate (DDR) cycles, the KT-2Pro offers timing control (20ps steps) and accuracy (+/- 150ps) to match the high frequencies.
Behavioral Test Technology (BTT ) is a revolutionary, patented technology proven world wide. It can identify memory malfunctions that escape usual testing methods. The King Tiger Memory Test System [uses this technology] is designed to test and identify problems in DDR memory devices and modules that may have passed every usual manufacturing test, but which can still fail in normal use. BTT allows the memory test engineer to integrate the signals from the King Tiger System into a traditional test environment and afford the engineer the highest level of test correlation currently available.
* Unit Serial No. 110.0030.00141
* 2 x KT-2 Pro DDR2 FB DIMM(FS) Load Board (P/N: 680.0276.029 / Rev. 02)
* 1 x Field Service and Maintenance Manual
* 1 x Intel Pentium 4 / 2.8GHz/800MHz/1MB L2 Cache CPU
* 2 x 512MB/400Mhz/DDR2 SDRAM (Dual interlaced) Memory modules
* 1 x Seagate ST340014AS SATA Hard drive 40GB
* 1 x Samsung SC-148A Slim CD-ROM
* 1 x National Instruments IEEE 488.2 PCI Interface Card
* Windows XP Professional COA Sticker on Case
* KTI Tigar Claw Software 2.3.0012 Installed
