Sharp ar-M160 copier, printer
Type: Digital simplex copier-based MFP, desktop
Copy System: Dry electrostatic transfer system
Originals: Sheets, bound documents
Original Size: 11" x 17" maximum
Copy Size: Min. 5 1/2" x 8 1/2", Max. 11" x 17"
Copy Speed: 16 copies per minute (8 1/2" x 11") 12 copies per minute (8 1/2" x 11"R ) 10 copies per minute (8 1/2" x 14") 9 copies per minute (11" x 17")
Continuous Copy: Max. 99 copies
First Copy Out Time: 7.2 Seconds
Zoom Range: 25% to 400% in 1% increments (with SPF 50-200%)
Fixed Zoom Mode: 50%, 64%, 77%, 95%, 100%, 121%, 121%, 129%, 141%, 200%
Exposure System: Fixed optical source, slit exposure (stationary platen) with automatic exposure
: Standard: (1) 250-sheet paper cassette with automatic feed (1) 100-sheet manual bypass tray
Optional: (1) 250-sheet paper feed unit or (1) 500-sheet paper feed unit (250 x 2)
Original Feed System: Standard: Original table with platen cover
Optional: 40-sheet single pass document feeder (SPF)
Paper Type: Paper Cassettes: 15-24 lb. standard or recycled bond paper Bypass Tray (multi-sheet feed): up to 100 sheets 15-20 lb. standard bond or recycled bond paper, up to 30
sheets for postcards, up to 5 sheets for envelopes (#10 monarch) Bypass (single-sheet feed): 15-54 lb. standard or recycled bond paper, OHP, Labels, and envelopes.
Memory: 16 MB (shared), expandable to 288 MB with options
Copy Resolution: Scan: 600 DPI, Output: 600 DPI
Exposure Modes: Photo Mode: 600 x 600 dpi
Gray Scale: 256 gradations/2 levels
Copy Features: Scan-Once Print-Many, Auto Paper Sensing (APS), Auto Magnification Sensing (AMS), auto tray switching, memory copy, manual zoom.
Output Tray Capacity: 250 sheets (face down)
Offset Stacking: Standard paper shifter (multi-page sort requires AR-EB7)
Developer System: Magnetic brush development
Light Source: Cold cathode lamp
Power Requirement: AC 120 V, 60 HZ, 12 Amps
Power consumption: Max 1200 W, stand-by 5 W
Dimensions: 23 15/64"(w) x 21 15/32"(d) x 18 33/64"(h)
Print Speed: 10 pages per minute/16 pages per minute with optional AR-EB7 Function Upgrade Kit
Emulation: Host-based/JBIG speed enhanced host-based with optional AR-EB7 Function Upgrade Kit
Software: Print driver, Printer Status Monitor
Read Once Print Many: Available with optional AR-EB7 Function Upgrade Kit, up to 50 pages @ 600 dpi
Interface: Standard: IEEE 1284 (ECP) parallel port, USB 1.1
Optional: USB 2.0 with optional AR-EB7 Function Upgrade Kit
Page Memory: 16 MB (shared), expandable to 288 MB with options
Features: Offset print, status monitor, N-up printing, fit to page, watermark, center position
Type: Flat head full color scanning system
Scanning Style: Platen/original feeder
Resolution: Basic: 600 x 1200 dpi
2, setting range 50 9600 dpi3
Scanning Method: Original cover/SPF
Output: 8 pixels/bit, A/D 12 bit
Protocol: TWAIN, WIA (Windows XP)
Interface: USB 1.1/optional USB 2.0 upgrade with AR-EB7 Function Upgrade Kit
Software: Sharpdesk integrated desktop document management software,
Scanner Keys: 6 Scan to Desktop destination keys (requires Button Manager)
