> New large cnc 4 axis knee mill conversion retrofit all
New large cnc 4 axis knee mill conversion retrofit all
Lowcost CNC Automation Package!!!
**4 Axis 7amp Micro Stepping Stepper Motion controller with 2 internal opto output relays 120vac 60hz **
**RAPID 55vdc / 700w / 120vac 60hz Power Supply**
**Jog Pendant Remote (Ver.3) Mill / Router version (USB)**
**1/ Large NEMA 23 / 370oz.in HYBRID magnet Stepper Motor (DUAL Shaft) including 8ft ready wired motor lead for the 4th Axis**
**3/ Large NEMA 34 / 1200oz.in HYBRID magnet Stepper Motors (Single Shaft) including 8ft ready wired motor leads for the XYZ Axis,s**
**Quickstart CDRom, including setup instuctional Booklet and 25pin F/M printer cable**
**(9) Limit and Home Switches**
..........OPTIONAL EXTRAS..........
Registered MACH 3 Licence is Available for only an additional $125 US (With system only at this price)
Larger Stepper Motors Add $108 per axis to UPGRADE to the large 2550oz.in NEMA 34 type or $195 to the NEMA 42 / 2990oz.in
WATCH THE VIDEO OF THIS SYSTEM WORKING ON A LARGE KNEE MILL >> http:// /watch?v=AsXsjcG0cVE&feature=channel_page
Seen below are examples of what can be powered
from this very controller package
4th Axis NEMA 23 motor can be used for an indexing table
Courtesy of Peter Fossey Australia
CLICK HERE TO SEE OTHER CONVERSION PACKAGES & EXAMPLES.
(1) One Industrial 4 Axis 7amp (EXTRA DUTY) 1/10th resolution Industrial Motion Controller
Including 2 buiit-in opto relays for switching ON/OFF other remote coolant, spindal devices via the software
(3) Three Large Very Powerful 1.8deg. Hybrid magnet 1200oz.in Stepper Motors pre-wired with 8ft leads tested.
(1) 1.8deg. Hybrid magnet 370oz.in Stepper Motor pre-wired with 8ft leads tested.
(1) Rapid Drive 700 Wattt / 55vdc Power Supply (120 or 220vac)
Color installation pictures are included NO ELECTRICAL EXPERIECE REQUIRED
Power supply box come ready wired and tested.
NEW!!! VER 3: Jog Remote ROUTER / MILL Pendant with jog and cutting speed capabitity
Absolutely............We supply you with whats a Quickstart XML. file you simply drag into your MACH 3 folder
This has all the motor and relay pinouts already preset so you can be indexing the motors on your test bench within minutes of setup
We also offer tech support on all our product range to assist you in this process
What size motors can this system run......?
This is a true Industrial 7amp Stepper Controller (Not a un-proven kit made at home) which is capable of running large stepper motors up to the 2950oz.in NEMA 42 size
Capable of powering large 12' x 8' Router table, 20' x 14' Plasma table or a large Knee milling machine
This motion controller has (4) opto output relays.........What do these do......?
Opto relays allow you to activate your machines spindle motor or coolant pump valve devices via the command of the software cycle
Very handy feature ensuring minimal loss of coolant.
How does the limit and HOME switch inputs work ......?
The limit switch and HOME switch inputs are accessed at the rear of the motion controllers 25pin patch connector socket.
Whats the Maximum input voltage this Motion controller can handle......?
All our 7amp controllers can run from 24vdc up to 80vdc
Our tests have proven the 55vdc transformer type power supply included in this package is more efficient and reliable in the long term
than switchmode type power supplies, delivering maximum torque to the stepper motors when required.
What software do you recommend......?
Almost any compatiable TTL or step/dir software maybe used.......
However you will find the most versitile program for Milling, Lathe or Plasma / Router work is MACH 3 by Artsoft
This program is costs only $179US to register the FULL VERSION through or Artsoft or is only $112 with a system
Do you sell different type systems?
Yes we cater for all types of different applications from a sherline Mill or hobby lathe right up to a large size Floor Milling machine
Are stepper systems as accurate as servo systems?
Do Stepper systems have the same accuracy as Servo systems?
The answer is "YES" there is no accuracy difference between them, they both accept and process the computers step/dir pulses in the same way.
All Mach 3 products work with our systems
WE CAN BE CONTACTED DIRECTLY FOR MORE TECHNICAL DETAIL over the Telephone on 61+ 0431 578373 AEST
EMAIL ME FOR MORE TECHNICAL INFO CLICK HERE
OTHER ADD-ON PRODUCTS CLICK HERE
