Endevco 102 isotron conditioner with 109 power supply
Endevco 102 Isotron Conditioner with 109 Power Supply
The ENDEVCO Modal 102 Signal Conditioner is a two-channel signal conditioner designed tor use with remote charge convertors, ENDEVCO ISOTRON accelerometers or other integral electronic piezoelectronic transducers. It supplies constant current to power the transducer or remote charge convertor. The Model 102 provides an AC voltage output proportional to the acceleration input. The Model 102 is designed to be used with the Model 109 Power Pupply. It has selectable sensitivity of 1 to 1099mV/g
The ENDEVCO Model 109 Power Supply provides DC power for up to four Series 100 Signal Conditioners in any combination. The 15 VDC powers the signal conditioner circuits. The 24 VDC provides compliance voltages for the Model 102 ISOTRON Signal Conditioner and excitation voltage source to the Model 106 Bridge Signal Conditioner.
