1991 miyano anc-45 5-axis cnc lathe w/fanuc 11TT
1991 MIYANO ANC-45 5-AXIS CNC LATHE w/FANUC 11TT
MIYANO 5-AXIS CNC TURNING CENTER
* LIVE TOOLING * FULL C-AXIS *
BAR CAPACITY.......................... 1-3/4"
MAX. WORKING LENGTH................... 14-3/8"
SPINDLE SPEED (MAIN).................. 40 - 4000 RPM
SPINDLE SPEED (SUB)................... 40 - 4000 RPM
SLIDE STROKE (X-AXIS)................. 6-5/16" / 5-1/2"
SLIDE STROKE (Z-AXIS)................. 17-29/32"/7-7/8"
SLIDE STROKE (B-AXIS)................. 17 5/16"
MAIN SPINDLE MOTOR.................... 20 HP
SUB SPINDLE MOTOR..................... 5 HP
APPROX. DIMENSIONS.................... 118"x85"x79"
APPROX. WEIGHT........................ 17,600 LBS.
- 12 POSITION UPPER TURRET (6) LIVE POSITIONS
- COLLET CHUCKS ON MAIN SUB SPINDLE
** PLEASE NOTE BARFEED IN PHOTOS IS NOT INCLUDED **
TO VIEW A VIDEO OF THIS MACHINE COPY AND PASTE THE FOLLOWING LINK ON
http:// /watch?v=8JpxxTGMJQA&feature=email
