Cincinnati-milacron monoset tool & cutter grinder, tool
Cincinnati-Milacron Monoset TOOL & CUTTER GRINDER, TOOL
Cincinnati-Milacron Monoset TOOL & CUTTER GRINDER, TOOLING, MTRZ'D WKHD.,.
CINCINNATI MONOSET Tool + Cutter Grinder,
Model MT, S/N 3152A178-0084, New 1978
Lead generated by spiral lead mechanism, min. 1.81
Length between spindle nose and tail center, max. 6
Offset slide travel, total 5.25
Range: Work head angular adjustment
Horizontal plane(turnable base) 235
Vertical plane above center 40
Vertical plane below center 40
Vertical slide travel total 9.5
(3) Wheel head spindle speeds 4000, 5729, 8000 RPM
(1) Work Head Spindle speed 436 RPM
(3) Index plates for spiral lead indexing unit:
(26) Straight cylindrical collets ranging in size from 5/8" to 1-7/32" with (12)
adapters that fit into the straight cylindrical collets and are used when
Hard chrome ways on three slides
1/4 HP 3/60/230-460 volt motorized workhead
1/2 HP 3/60/230-460 volt wheelhead drive motor
Machine wired for 3/60/230 Volt operation
Floor space required: 60 x 67 x 62.12 (Max.height)
PRICE: F.O.B Truck, Hauppauge, NY
Machine Location: Long Island, NY
