Unipower DPG1U-A2-B3-c-f fuse distribution panel
Unipower DPG1U-A2-B3-C-F fuse distribution panel
* Unipower Telecoms DPG1U SeriesGMT fuse distribution panel
* One Mounting Position High (1.75")
* 19- or 23-Inch Rack Mounting
* Operating Voltage: 12 24 or 48 VDC
* Positive or Negative Ground
* A & B Can Be Separately Configured
* Two Form C Relay Contacts per Load
* Rack Offset Every " Front to Back
* TECHNICAL SPECIFICATIONS INPUT / OUTPUT:
* Panel Capacity: 80A Per Bus 160A Total
* Dual Bus with 10 Fuses Each
* Polarity2: Positive or Negative Ground
* Alarm Indicator: Dual-Color LED Per Bus
* Alarm Connections: 2 Form C Relay Contacts Per Bus
* SAFETY STANDARDS: UL1950 CSA22.2 #950 EN60-950
* Input Connections: Crimp Type Lug or -20 Stud
* Output Connections: Barrier Terminal Strips
* Chassis Ground Connection: No. 8-32 Stud
* Fail Alarm Connections: 0.045" sq. Wirewrap Pins
* Cables and connectors not included.
* A & B indicator lights on front panel.
