Ex-cell-o 602 milling machine part manual 52672 xlo
This is a reproduction, not a photocopy, of an original Ex-Cell-O (XLO) 602 Instructions and Parts Manual No. 52672. This manual contains operating instructions, adjustments, maintenance, lubrication, and a complete set of exploded view diagrams of the parts with description. Please read index below.
Installation...................................2
Lubrication....................................3
Operating Instructions.........................4
Service Information............................6
Ordering Instructions..........................6
Operating Temperature..........................6
Vibration......................................6
Adjusting Gibs.................................6
Spindle Brake & Lock Adj.......................6
Removing Vari-Speed Cover......................6
Spindle Belt Replacement.......................7
Replacing Quill Return Spring..................7
Removing Spindle Quill Sub Assembly &
Replacing Quill Guard..........................8
Lead Screw Back Lash Adj......................15
Machine Specifications.........................9
Machine Ass'y Dwg. & Stock List...............10
Back Lash Eliminator Dwg. & Stock List
(Optional)................................... 15
Spring Loaded Table Handwheels (Optional).....15
Head Ass'y Dwg. & Stock List..................16
Right Angle Attachment (Optional).............24
Table Power Feed Ass'y Dwg. & Stock
List (Optional)...............................25
O.P.L. Optical Measuring Attachment
(Optional)....................................30
D.O.M. Direct Reading Optical Measuring
Attachment (Optional).........................31
