> 9" swg hardinge DSM59 second op lathe, vari-speed,5C-co
9" swg hardinge DSM59 second op lathe, vari-speed,5C-co
9" Swg Hardinge DSM59 SECOND OP LATHE, Vari-Speed,5C-Co
9" Swing Hardinge DSM59 SECOND OP LATHE, Vari-Speed,5C-Collet Closer,Turret & CrossSlide,
MODEL: DSM-59, S/N: DV-59-15947, NEW: 1980
ROUND 5C COLLETS ............... 1-1/16"
HEXAGON 5C COLLETS ............. 7/8"
SQUARE 5C COLLETS .............. 3/4"
STEP CHUCKS .................... 1-1/16" TO 6"
JAW CHUCKS ..................... 5"
JAW CHUCKS THROUGH SPINDLE ..... 1-5/32"
SPINDLE NOSE ...................... HARDINGE TAPER.
LENGTH OF BED ..................... 36"
SWING OVER BED .................... 9"
TRAVEL OF DOUBLE TOOL CROSS SLIDE . 3-3/4"
TRAVEL OF TURRET SLIDE ............ 4"
DIAMETER OF TURRET HOLES .......... 3/4"
VARIABLE SPINDLE SPEED RANGE ...... 230 TO 3,500 R.P.M.
- HEXAGON TURRET WITH (2) 1/32"-1/2" CAPACITY ALBRECHT DRILL CHUCKS
- DOUBLE TOOL CROSS SLIDE WITH (1) TOOL HOLDER
- PUSH BUTTON CONTROL FOR VARIABLE SPEED
- BALL BEARING LEVER COLLET CLOSER
- 3/8-3/4 H.P. 3/60/230 VOLT TWO-SPEED MAIN DRIVE MOTOR & ELECTRICAL CONTROLS
