Allen bradley 1794-IR8 /a 1794IR8 17941R8 flex i/o rtd
Rockwell Automation > PLC & HMI > I/O Products > Flex & Flex Ex > 1794-IR8/A
Allen-Bradley 1794-IR8 Flex I/O Resistance Temperature Detector (RTD) Input Module, 8 Points, Series A
Number of Inputs: 8 Channels; Module Location: Cat. No. 1794 TB2, TB3, TB3T Terminal Base Unit; Signal Input Range: 1 to 433 ohms; Resolution: 16 bits across 435 ohms; Data Format: 16 bit 2's complement or offset binary (unipolar); Normal Mode Noise Rejection 60db @ 60Hz for A/D filter cutoff @ 10Hz; Nominal Supply Voltage: 24V DC; Voltage Range: 19.2 to 31.2V DC; Supply Current: 140mA @ 24V DC.
Allen-Bradley 1794-IR8 RTD 8 Input Flex I/O Analog Input Module is a block transfer module that interfaces analog signals with any Allen-Bradley programmable controllers that have block transfer capability. Block transfer programming moves input or output data words between the module s memory and a designated area in the processor data table. Block transfer programming also moves configuration words from the processor data table to module memory.
One Allen Bradley 1794-IR8 Series A, Flex I/O Resistance Temperature Detector (RTD) Input Module, 8 Points, in excellent working and cosmetic condition.
