Yr 2000 mori-seiki cl-253A cnc lathe w/msg-803 control
Yr 2000 MORI-SEIKI CL-253A CNC LATHE w/MSG-803 CONTROL
MORI SEIKI CL-253A CNC LATHE WITH GANTRY LOADER AND WORK STOCKER
SWING OVER BED ...................... 20.47"
SWING OVER CROSS SLIDE .............. 16.14"
MAXIMUM TURNING DIAMETER ............ 17.71"
MAXIMUM TURNING LENGTH .............. 18.9"
BAR WORK CAPACITY ................... 2.64"
X-AXIS TRAVEL ....................... 10.24"
Z-AXIS TRAVEL ....................... 19.69"
SPINDLE SPEED RANGE ................. 30-3500 RPM
SPINDLE NOSE ........................ A2-8
HOLE THROUGH SPINDLE ................ 3.14"
NUMBER OF TURRETS ................... 1
TYPE OF TURRET ...................... 10 STATION
SQUARE SHANK HEIGHT OF TOOL ......... 1"
SHANK DIAMETER OF BORING BAR ........ 2"
RAPID TRAVERSE RATE X/Z ............. 708/944 IPM
SPINDLE DRIVE MOTOR ................. 20/15 HP
APPROXIMATE WEIGHT .................. 13,500 LBS.
- MORI SEIKI MSG-803 CNC CONTROL
- LG-10 GANTRY W/14 STATION WORK STACKER
