Associated research hypot tester quadcheck 6554SA +gpib
Associated Research Hypot Tester Quadcheck 6554SA +GPIB
* Input power: 98-132/196-165VAC (user select) 47-63Hz 10/5A
* Output: 0-5kVAC @ 0-40mA, 0-5kVDC @ 0-40mA
* ARI Quadcheck Model 6554SA
* 36541 U.S. Receptacle Box for Hipot & Ground Bond (115V)
* Operation & Service Manual
* Certificate of Calibration (from 2001)
The 6554SA is four instruments in one box. It is able to check AC Hipot, DC Hipot, Insulation Resistance and run High Current Ground Bond Testing. It features IEEE-488 (GP-IB) communications/control and a benchtop OR rack-mountable cabinet.
