New yaesu vx-6R dual-band ham radio transceiver VX6R
Dual Band Submersible Handheld Transceiver
The VX-6R is an ultra-rugged 144-430 MHz FM Hand-Held featuring wide receiver coverage, JIS7 submersibility, the Yaesu-exclusive Emergency Automatic Identification (EAI) system, and ultra-simple keyboard access to important features.
New on the VX-6R is the One-Touch Direct Memory Recall feature, that allows you to recall ten favorite memories with a single button press, just like on your car stereo.
The VX-6R comes equipped with a high-capacity 1400 mAh Lithium-Ion Battery Pack
FNB-80LI 1400mah Battery Pack
* Direct Memory Recall feature provides One-Touch Stored Frequencies Access, just like on a Car Stereo!
Huge 900-Channel, 24-Banks Memory System
Three Special Memory Banks for Shortwave, Marine, and Weather Broadcast Stations!
* Ergonomic Design is Ideal for Operation when Wearing Gloves
* Outdoor-ready Features including Waterproof Rating, Emergency Automatic ID (EAI) system, and Weather Sensor Capability
Compact Polycarbonate Resin and Aluminum
Die-Cast Case with Solid Waterproofing Seal
(guaranteed at depth of up to 3 feet for 30 minutes)
* Weather Sensor Capability
Three Powerful Emergency Features:
EAI Feature: Ideal for Outdoor Operation!
Easy-to-Use Ultra-Bright Emergency Flashing LED
* Five Watts of Power Output, using High-Capacity Lithium-Ion Battery (supplied)
* Wide-band Receiver Coverage for Catching All the Action!
* Convenient Selective Calling and Paging Features!
New Two-Tone CTCSS Paging
50-Tone CTCSS Tone Squelch and Digital Code Squelch Systems
Auto-Range Transponder System (ARTS)
* Versatile Scanning for the Monitoring Enthusiast!
* Outstanding Power-Management Features
New "Wake-Up" Feature Checks for Activity when Radio is Turned Off!
Additional battery saving features
* Big-Radio Features in a Compact Package!
* Performance Features for the Experienced Hand-Held User!
1.8 - 30 MHz (Shortwave Band)
30 - 59 MHz (6 Meter Amateur)
137 - 174 MHz (144 MHz HAM)
222 - 420 MHz (ACT1: Action Band 1)
420 - 470 MHz (430 MHz HAM)
803 - 998.99 MHz (ACT2: Action Band 2 Cellular Blocked)
Frequency Range Transmit: 0
5/9/10/12.5/15/20/25/50/100 kHz
5 ppm @14 F to +122 F (-10 C to +50 C)
1.6/5.0/7.6 MHz (430 MHz)
5-16 VDC Negative Ground EXT DC Jack
60 mA (Standby, Saver Off)
900 A (ON Timer Activated)
1.6 A (5 Watts TX, 144 MHz)
1.5 A (1.5 Watts TX, 222 MHz)
1.8 Amps (5 Watts TX, 430 MHz)
2.3x3.5x1.1 inches (58x90x29 mm) (without knob and antenna)
9.5 oz (270g) with FNB-80LI, and antenna
N-FM, AM Double-conversion, W-FM Triple Conversion
1.5 V TYP for 10 dB SN (0.5-30 MHz, AM)
0.35 V TYP for 12 dB SINAD (30-54 MHz, NFM)
0.5 V TYP for 12 dB SINAD (54-76 MHz, NFM)
0.5 V TYP for 12 dB SINAD (54-59 MHz, NFM: USA)
1 V TYP for 12 dB SINAD (76-108 MHz, WFM)
1 V TYP for 12 dB SINAD (59-108 MHz, WFM: USA)
1.5 V TYP for 10 dB SN (108-137 MHz, AM)
0.2 V for 12 dB SINAD (137-140 MHz, FM)
0.16 V for 12 dB SINAD (140-150 MHz, FM)
0.2 V for 12 dB SINAD (150-174 MHz, FM)
0.5 V TYP for 12 dB SINAD (174-250 MHz, WFM)
0.5 V for 12 dB SINAD (300-350 MHz, NFM)
0.2 V for 12 dB SINAD (350-420 MHz, NFM)
0.18 V for 12 dB SINAD (420-470 MHz, NFM)
1 V for 12 dB SINAD (470-540 MHz, WFM)
1 V TYP for 12 dB SINAD (580-800 MHz, WFM)
0.5 V TYP for 12 dB SINAD (800-999 MHz, NFM)
AM, N-FM: 12 kHz/35 kHz (-6dB/-60dB)
W-FM: 200 kHz/500 kHz (-6dB/-20dB)
200 mW @ 8 Ohms for 10% THD (@ 7.4 V DC)
400 mW @ 8 Ohms for 10% THD (@ 13.8 V DC)
144/430 MHz 5.0/2.5/1.0/0.3 watts
222 MHz 1.5/1.0/0.5/0.2 watts
Variable Reactance F2D, F3E
Specifications are subject to change without notice and are guaranteed within amateur bands only.
Frequency ranges and repeater shift may vary according to transceiver version world-wide.
VX-6R's accessories (not included)
There are original accessories of VX-6R. Please browse our listings if you are interested.
