LM339 am - quad differential comparators - ti - 25/lot
LM339 AM - QUAD DIFFERENTIAL COMPARATORS - TI - 25/Lot
LM339AM - QUAD DIFFERENTIAL COMPARATORS - TI - 25/Lot - NOS
Single Supply or Dual Supplies
Max Rating . . . 2 V to 36 V
Tested to 30 V . . . Non-V Devices
Tested to 32 V . . . V-Suffix Devices
Low Supply-Current Drain Independent of
Supply Voltage . . . 0.8 mA Typ
Low Input Bias Current . . . 25 nA Typ
Low Input Offset Current . . . 3 nA Typ (LM139)
Low Input Offset Voltage . . . 2 mV Typ
Common-Mode Input Voltage Range Includes
Differential Input Voltage Range Equal to
Maximum-Rated Supply Voltage . . .
Output Compatible With TTL, MOS, and CMOS
These devices consist of four independent voltage
comparators that are designed to operate from a
single power supply over a wide range of voltages.
Operation from dual supplies also is possible, as
long as the difference between the two supplies is
CC is at least 1.5 V more positive
than the input common-mode voltage. Current drain
is independent of the supply voltage. The outputs
can be connected to other open-collector outputs to
