Northern / honeywell aep-3 expanded relay bd 8 output
Northern Computers (now Honeywell)
For Use with Northern Computers', now HONEYWELL N-1000-II, III or IV access control panels.
Excellent for Elevator Access Control
Expanded Relay Board 8 Outputs DPDT
Auxiliary output board. Provides 8 additional relay outputs to any N-1000 panel with version 5.10 or
newer firmware (excluding version 6). Up to two AEP-3 boards per N-1000 panel. Can be mounted
on the inside cover of the N-1000 control panel or separately in the ENC-1 enclosure. Contacts
are DPDT. Includes interconnecting cable (AEP-3-CBL). Requires separate 12 VAC 20 VA transformer
or 12 VDC power supply, linear @ 500 mA). Current draw is 150 to 325 mA. Dimensions: 6" H x 10"
W x 1.75" D, (15.24 cm H x 25.4 cm W x 4.445 cm D). Operating
temperature range: 35 -110 F (2 -43 C).
