Warner & swasey saddle type turret lathe model 1A
Warner & Swasey Saddle Type Turret Lathe Model 1A
Warner & Swasey Saddle Type Turret Lathe
Model No. 1A, M-3400 Lot 50
Maximum Swing Over Carriage Guard: 16-1/4"
Maximum Swing Over Bed Ways: 18"
Maximum Distance End of Spindle to Turret Face: 43-3/4"
Hexagon Turret Travel: 34-7/8"
Longitudinal Feed Rates (16): .004" - .149"/Rev.
Rapid Traverse Rate: 34-1/2 FPM
Maximum Turning Length: 32-1/8"
Cross Slide Longitudinal Travel: 34-7/8"
Cross Slide Feed Rates: .002" - .0073"/Rev.
Cross Slide Longitudinal Feed Rates: .004" - .149"/Rev.
Spindle Speeds: 20 - 1497 RPM
Hole Thru Spindle: 3" Diameter
Overall Machine Dimensions: 72" x 140" x 66" High
B&L Acu-Rite III 2-Axis DRO, Cross Feed & Turret Feed, .0005" Increments
12" 3-Jaw Manual Chuck with 2-Piece Reversible Hard Jaws
Thread Chasing Attachment with Automatic Knockoff
(4) Vertically Adjustable 2-Position Boring Tool holders
(2) Plain Boring/Drilling Holders
15/30 HP 2-Speed Motor 230/3/60
Approximate Net Weight: 9,500 Lbs.
