Tecsun pl-360 pll dsp with etm am/fm/sw/lw antenna/gift
TECSUN PL-360 PLL DSP ETM with FM/AM/SW/MW/LW antenna/Gift NEW
1.2010 year, the best new product,latest style,
2.Original packaging and accessories produced by the manufacturer,100% Quality Guarantee.
3.New, Never used. 100 % FULL CHECK AND QC PASSED.
4.Gift:1pcs Rechargeable batteries set & 1pcs USB Cable,(And additional A stereo headset , original price is $5)
1 pcs Stereo headphones, 1pcs protective cover, 1pcs external FM / shortwave antenna, 1pcs the long-wave external antenna.
The machine adopts the si4734 U.S. SILICON LABS digital signal processing (DSP) chip, the analog FM / AM digital broadcasting signal conversion, the use of modern software radio principle of its processing and demodulation, which greatly increased the sensitivity to listen, choose sex, SNR, and anti-jamming capability
can receive FM stereo, AM (can be extended to long-wave), short wavelength (2.3 ~ 21.95MHz) radio programs, features and more practical, simple, special power
FM receiving frequency range can be set to receive 76 ~ 108MHz (Japan standard), 87 ~ 108MHz, or 87.5 ~ 108 MHz (European standard)
External antenna jack with AM, AM with the supplied external antenna can greatly improve the AM / L-band receiver sensitivity
has a very useful multi-function digital adjustment knob, can be used to set the time, adjusting the frequency, select the address
Taiwan has five electoral mode: easy tuning (ETM), manual search radio frequency (VF), manual search stored radio (VM), browsing, radio frequency, browsing, stored stations, which is de ETM Health units to increase revenue collection efficiency and unique platform approach
can be manual, semi automatic (ATS) to store up to 450 radio frequencies, including FM / in the long wave can each save 100, 250 short-wave frequencies can be kept
multi-function display: can display the radio frequency, electric field strength, signal to noise ratio, temperature, battery capacity status, etc.
Use a special high sensitivity film speakers, sound beautiful, listen to FM stereo radio with headset
has broadcast regular boot, you can listen to a pre-boot time radio programs, can also be set to 90 minutes in an auto-stop function alarm ring
highly intelligent power switch function: You can set the boot 1 to 120 minutes after the automatic shutdown, but also cancel the automatic shutdown feature
Use the three R6 (V) battery, you can also use nickel-metal hydride batteries and intelligent battery charging (USB jack)
fine comes with protective cover, AM antenna and external high sensitivity stereo headphones
PL-360 basic technical indicators:
Frequency Range / Tuning step
76 - 108 MHz; smart step 0.01/0.1 MHz
Can choose the frequency coverage:
Standard: 87 - 108 MHz (applies in Japan, Germany, Russia, other than national standards)
Japan: 76 - 108 MHz (including part of the campus radio and national 4 - 5 channel TV audio)
2300 - 21950 kHz; Smart Step 1 / 5 kHz
522 - 1620 kHz; Smart Step 1 / 9 kHz (for Asia, Africa and Europe)
520 - 1710 kHz; Smart Step 1 / 10 kHz (for North America)
150 - 1620 kHz; (covering long wave) Intelligent Step 1 / 9 kHz
Frequency Modulation (FM) (S / N = 30dB) better than 3 uV
AM (MW) (S / N = 26dB) better than 2 mV / m built-in antenna
AM (MW) (S / N = 26dB) better than 1 mV / m external antenna
Long Wave (LW) (S / N = 26dB) better than 12 mV / m built-in antenna
Long Wave (LW) (S / N = 26dB) better than 4 mV / m external antenna
Short wave (SW) (S / N = 26dB) better than 30 uV
Frequency Modulation (FM)> 60 dB
FM stereo separation: better than 25 dB
Headphones: 10 mW / 8 - 32 stereo headphones
the number of stored memories: a total of 450
Frequency modulation (FM) 100
Naoxing mode: radio alarm rang
Frequency Modulation (FM) <25mA
AM / long wave (MW / LW) <23mA
Speaker Size: diameter 40 mm / 16 Film Speaker
Battery: 3 R6 (V) batteries or rechargeable batteries
External power jack: USB specification / DC 5V 300mA
weight: About 128g (without batteries)
Physical Size: W 159 53 high thick 26 (mm)
1 pcs Stereo headphones, 1pcs protective cover, 1pcs external FM / shortwave antenna, 1pcs the long-wave external antenna, 1pcs instruction manual
