Nakamura-tome methods slant model 3B cnc turning center
Nakamura-Tome Methods Slant Model 3B CNC Turning Center
http:// /watch?v=y14KggOYVIU
Nakamura-Tome Methods Slant 3
Maximum Swing Over Bed Ways: 31.1"
Maximum Swing Over Saddle: 18.9"
Maximum Machining Diameter: 15.75"
Maximum Turning Length: 21.26"
Distance Spindle Nose to Turret Face: 7.48" - 30.31"
Maximum Distance Between Centers: 28.94"
Longitudinal Carriage Travel, Z-Axis: 22.83"
Transverse Turret Slide Travel, X-Axis: 10.83"
Spindle Speeds, 2 Ranges - Variable: 35 - 3500 RPM
Maximum Bar Capacity: 2.5" Diameter
Number of Stations on Tool Turret: 12
Overall Dimensions: 116" x 78" x 86" High
Fanuc 6T CNC Control with CRT, RS232 & RPG
Splash Guards with Safety Door Interlock
Miscellaneous Turret Tooling
25 HP AC Spindle Motor 220/3/60
