3434 dual shaft shear shredder grinder for tire tires
3434 DUAL SHAFT SHEAR SHREDDER GRINDER - TIRE SHREDDER
Cost is for the base unit price.
* 10 HP TO 150 HP DEPENDING ON RPM AND TORQUE SELECTED FOR PROCESSING MATERIALS
* SHAFT CENTER DESIGN 13 ON THE CENTER TO CENTER DISTANCE WHICH ALLOWS FOR A 5.5 SHAFT ON THE FLAT AND 17.5 ON THE TIP TO TIP DISTANCE FOR THE CUTTER ( DOUBLE HOOK )
* FRAME DESIGN DUAL DRIVE WITH VERTICAL SHAFT REMOVAL DESIGN
* TYPICAL SHREDDER LENGTH 104
* TYPICAL SHREDDER OPENING LENGTH - 52 ( FOR PALLETS AND TIRES )
* EXTENDED SHREDDER OPENING FOR RECYCLING OVERSIZE MATERIALS 62
* MULTI-PURPOSE SHREDDER OPENING FOR COST SAVINGS 34
* TYPICAL SHREDDER WIDTH 55
* TYPICAL WIDTH OF SHREDDER OPENING WHICH IS BASED ON THE CENTER TO CENTER DISTANCE OF THE SHAFTS WHICH IS 13 AND IS TYPICALLY 32 TO 40 FOR MOST APPLICATIONS. STANDARD WIDTH IS 34 ON THIS MACHINE.
* DEPENDANT ON THE VOLUME OF MATERIAL NEEDED FOR PROCESSING; ORDER MAY BE BETTER SUITED TO THE 5444 OR 7272 MODELS
PRICE RANGE OF THESE MACHINES IS ABOUT $65,000.00 TO $80,000.00
PRICING DEPENDS ON THE THROAT OPENING, THE HP AND SHAFT SPEED, THE CUTTER WIDTH AND OTHER FACTORS SUCH AS RAM FEED HOPPERS AND BOMB BAY SCREEN DISCHARGE DESIGNS.
* BASE MACHINE NORMALLY NEEDS AN INFEED CONVEYOR AND A DISCHARGE CONVEYOR BUT LOADING FROM A BOBCAT OR LOADER AND DISCHARGE TO PILE AREA UNDER SHREDDER STAND ARE OTHER OPTIONS THAT CAN BE USED.
* PRICE INCLUDES SHREDDER, FRAME, HOPPER, STAND, MOTORS, GEARBOXES AND MOTOR AND STARTER CONTROL PANEL.
WE HAVE COST SAVINGS WITH OUR WORLDWIDE MANUFACURING ABILITY THAT OTHERS SIMPLY DO NOT HAVE
