Ese-991U broadcast timecode large 2IN led timer display
ESE ES-991U/TZ Broadcast Remote Timecode Display
Was $535 (here) Large 2.3 Inch Yellow LED 4 Digit Display
The ES-991U is a Time Code display featuring 2.3" yellow LED displays. The unit accepts, via the rear-mounted BNC connector, either ESE Time Code (TC76 , TC89 , or TC90 ) or SMPTE/EBU Time Code. RS-232C ASCII Time Code (format "0", "1" or "A" at 9600 baud) may be input via the rear-mounted 9-pin connector. The 991U will automatically determine which code is being received. An internal DIP switch is used to configure the display for 12 or 24 Hour format, or to display the Date instead of time-of-day (if incoming time code contains Date information, such as ESE TC90, date-encoded SMPTE/EBU or ASCII formats "1" or "A"). If receiving ESE Time Code from a timer, the unit will display Minutes & Seconds.
* Reads SMPTE/EBU, ASCII & ESE Time Code
* Four 2.3" Yellow LED Displays
* Switchable to Date display (Month-Day)
* Time Zone Offset Option Installed
