New grizzly 2 hp cyclone dust collector, G0440,
Cyclonic action separates the heavy dust particles from the fine particles and drops them into the 35-gallon steel drum. The fine dust travels past the 14-1/2" diameter impeller and is then trapped by a cartridge filter made of spun-bond polyester that filters 99.9% of particles from 0.2 to 2 microns in size. The cartridge filter is pleated to provide 86 square feet of surface area for efficient air movement and a clear plastic bag collects the fine cake that shakes off the filter for consistent dust collector performance. Casters mounted to the drum also make disposal of the larger chips and dust as easy as it gets. Other features include: a vertical motor support for reduced vibration, thick walled 11 gauge steel blower housing, 16 gauge steel cyclone body, 360 degree blower rotation for easy connection to a duct system, TEFC Class "F" motor and a magnetic switch. The optional steel legs and support frame (H7499) also make setup quick and easy.
* Impeller size: 14-1/2" steel, riveted
* Suction capacity: 1354 CFM @ 2.5" SP
* Maximum static pressure (inches of water): 10.4"
* Filter: 99.9% efficiency captures 0.2-2 micron dust particles
* Filter surface area: 86 sq. ft.
* Collection Drum: 35 gallons
* Overall dimensions: 59" wide x 37-3/4" deep x 93 -1/4" high
* Motor: TEFC Class "F", 2 HP, single-phase, 220V
* Cycle/RPM: 60 Hertz/3450 RPM
* Switch: Magnetic w/ remote control device
