> 5" shibaura bft-13C tbl type horizontal boring mill
5" shibaura bft-13C tbl type horizontal boring mill
5" SHIBAURA BFT-13C Tbl TYPE HORIZONTAL BORING MILL
5" SHIBAURA BFT-13C TABLE TYPE HORIZONTAL BORING MILL
5 TOSHIBA TABLE TYPE HORIZONTAL BORING MILL
MODEL: BFT-13C-W2, S/N 2732, NEW 1977
DIAMETER OF SPINDLE .................. 5.12
TAPER IN SPINDLE ..................... #50
DIAMETER OF MILLING QUILL ............ 8.86
SPINDLE LONGITUDINAL TRAVEL .......... 35.4
HEADSTOCK VERTICAL TRAVEL ............ 71.5
TABLE WORKING SURFACE ................ 47 X 98.4
TABLE CROSS TRAVEL ................... 98.4
TABLE LOAD ........................... 22,000 LBS.
TABLE LONGITUDINAL TRAVEL ............ 75.1
RAPID TRAVERSE RATE .................. 126 IPM
SPINDLE SPEEDS (27) .................. 9 TO 1200 RPM
HIGH SPINDLE SPEED RANGE .......... .0001 - .07 IPR
MEDIUM SPEED RANGE ................ .0006 - .315 IPR
LOW SPINDLE SPEED RANGE ........... .0003 - 1.73 IPR
APPROX. WEIGHT ....................... 60,280 LBS
DIMENSIONS ........................... 264"F-B x 218 W X 165 H
- TELSCOPIC WAY COVERS FOR CROSS & SADDLE TRAVELS
- 25 HORSE POWER SPINDLE MOTOR
Click Here For More Toshiba-Shibaura Machines
Click Here For More Boring Mills - TABLE TYPE HORIZONTAL BORING MILLS(s)
