> Maxim MAX8717E MAX8717 max 8717 8717E ev kit 28PIN ic
Maxim MAX8717E MAX8717 max 8717 8717E ev kit 28PIN ic
Model: MAX8717EVKIT
Pin Package: 28pin thin QFN
1. Those chipsets at the same function & set.
The MAX8717 evaluation kit (EV kit) demonstrates the MAX8717's standard application circuit. This dual-PWM synchronous DC-DC converter steps down high-voltage batteries and/or AC adapters, generating main supplies for notebook computers.
The MAX8717 EV kit provides dual 5V and 3.3V output voltages from the 6V to 24V battery input range. It delivers up to 5A output current for the 5V output and 5A for the 3.3V output with 95% efficiency. The EV kit operates at 300kHz switching frequency and has superior lineand load-transient response.
* 6V to 24V Input Voltage Range
3.3V at 5A (Adjustable from 1.0V to 5.5V)
5.0V at 5A (Adjustable from 1.0V to 5.5V)
* 300kHz Switching Frequency (Selectable 200kHz/300kHz/500kHz)
* Independently Selectable PWM, Skip, and Low- Noise Mode Operation
* Independent Power-Good Outputs
* Fully Assembled and Tested
