3M dynapro et 355 touch screen industrial lcd monitor
3M Dynapro ET 355 Touch Screen Industrial LCD Monitor
This is a 3M DynaPro industrial computer monitor with a 15" LCD display and touchscreen interface. This unit would be in Very Good cosmetic condition, but there are several minor blemishes in the plastic Moisture Deflector around the front bezel (see photos). We did not note any scratches/scuffs on the display area.
When we applied power, the monitor said it didn't have any input signal (it didn't), then it said it was going to sleep (which it then did). We are not sure what sort of video signal it is supposed to get over the CAT5 jack on the rear panel, but the display module inside accepts a plain analog RGB signal. We applied the video signal from one of our computers (not included) to the VGA connector and it gave a crisp, clear display. We are not sure how to connect the touch screen interface to our computer, so it was not tested. Please NOTE: the side panel that covers the connectors is missing, which compromises the explosion-proof nature of this unit. The description below is from a 3M product announcement online.
NO manuals or additional accessories are included if not shown. Photos show the actual item you will receive.
3M Touch Systems Dynapro ET 355 Series A Rev. 1.0 Factory Options:
3M Says: "3M Dynapro ET 355 industrial monitors are designed and certified to operate in a variety of harsh industrial environments, including oil and gas exploration, heavy industrial, military, mining and utility operations.
"Dynapro ET 355 monitors are fully sealed to meet the NEMA 4X rating and IP 66 industrial enclosure standard. Additionally, the Dynapro ET 355 monitor is certified for use in hazardous locations where harmful chemicals and harsh conditions exist.
"To extend the monitors' utility in the industrial workplace, a 1,000-foot cable and keyboard/video/mouse (KVM) extender kit enables the monitors to be placed up to 1,000 feet from the user's computer. This allows operators in the field to utilize the application while the high-performance PC is running 1,000 feet away in a cool, controlled environment. A moisture deflector option for outdoor use also is available.
"The 15-inch displays integrate the MicroTouch Near Field Imaging patented touch-screen technology, incorporating exceptional durability with high precision, optical clarity and brightness. Near Field Imaging touch-screens can withstand severe abrasions, harsh chemicals, shock and vibration, and variations in temperature and humidity, while maintaining positional accuracy."
