> Pir movement detector kit, sensitive to 18 feet K30
Pir movement detector kit, sensitive to 18 feet K30
can drive your own circuit for further expansion
RE200B PIR Sensor used in Kit 30
Essential specs on RE200B sensor
Circuit designed around a recently developed movement IC the KC778B. Circuit utilizes PIR detector and a light dependent resistor (LDR) to provide an optimized circuit that will detect motion up to 6 metres away. Operates on 9-12 VDC. Note that the PIR sensor & the PCB-mounted fresnel lens fit on the other side of the PCB; the solder side. This is to allow the unit to be mounted inside a container with the detecting lens poking out and the controls facing inside the box
DIY Electronics Kits are the most well-designed and documented kits available anywhere.
With over 200 Kits in production, and hundreds of thousands sold the world over, they offer excellent learning value, useability, and uniqueness.
