Agilent agl N2261A 40 channel gp relay module
Agilent AGL N2261A 40 Channel GP Relay Module
Previously labeled as Factory reconditioned. Original packaging and certificates from Agilent.
The Agilent N2261A General Purpose Relay Module provides 40 independent single-pole-single-throw (SPST) latching relays. Each channel can switch up to 200 V, 1 A, and 60 W or 62.5 VA. Thanks to an innovative driving circuit, 10 switching channels can be operated simultaneously, resulting in high throughput for an automatic test system. It can be operated in either SCPI mode or 3488A mode. A pair of signals can be switched together by using a pair of channels on two N2261A modules. The N2261A can be operated in single channel break-before-make (BBM) or multiple channels open/close mode. A connection terminal is not provided with the module.
* 40 independent relays in one module
* High speed switching in parallel operation
* Built-in relay cycle counters
