New port 370-rc clamp 426-x stage 600A-2R mount 75 stand
NEWPORT 370-RC CLAMP 426-X STAGE 600A-2R MOUNT 75 STAND
Rod clamps are a versatile foundation for mounting and positioning a variety of Newport components including translation and rotation stages, platforms, post holders, angle brackets and mirror mounts. These clamps can be positioned at any rod height and securely locked in place. They have a high-precision, long-bore interior that minimizes wobble and chatter as the clamp is positioned along a precision-ground rod.
600A Series Optical Mounts are designed to offer even greater versatility and functionality. The baseplate is detachable, which allows you to convert your mount to a left-handed version. Additionally, a third actuator can replace the pivot bearing to provide pure translation without tilt, eliminating the need for an additional linear stage. The mount possesses sound mechanical designs, including hardened inserts at the contact points of the kinematic mount. For higher resolution, the mounts may be fitted with 100 tpi AJS Adjustment Screws or DM-13 Differential Micrometers.
The model 75 Damped Rods are the most sophisticated rod available for critical applications where acoustical and vibrational forces are a concern. These rods incorporate cylindrical masses constrained by damping layers, concentrated in the upper portion of the rod where they are most effective in dissipating vibrational energy. This construction is the result of extensive computer modeling, dynamic testing and structural analysis. Newport s patented internal damping system provides unmatched vibrational immunity. Compared to the best alternative designs, Newport damped rods exhibit 60% higher resonant frequency, 100% faster vibration decay and 160% better peak compliance. These 14 in. (356 mm) long rods mount to tables and breadboards with four bolts through a special ring base and have with a nylon gear rack set into the rod for rack-and-pinion control over component elevation.
