True tcgd-77 dry curved glass display case 77"
The True TCGD-77 "dry" display case combines efficient, high volume merchandising with an elegant curved glass front for a sophisticated presentation of breads, desserts and pastries.
* Designed to provide an attractive companion to our forced-air refrigerated display case
* Single pane curved glass front and side panels provide extra large viewing area to maximize bakery product presentation. Front glass tilts forward for easy cleaning. Glass is tempered for safety
* Interior - NSF approved white aluminum sides and top, coved corners and high impact plastic floor
* Cabinet mounted on a welded, heavy duty galvanized frame rail. Rail dipped in rust inhibiting enamel paint for corrosion protection inside and out. Rail fitted with leg levelers
* Low-E , double pane thermal glass insert with mitered plastic channel frame
* Self-closing doors, efficient elastic tubing closure mechanism for smooth, even, positive closure
* Sliding doors ride on stainless steel V-Channel with stainless steel bearings. Doors fit within plastic channel frame
* Each door is fitted with a 12" long molded plastic handle
* Three (3) adjustable, heavy duty PVC coated wire shelves 71 3/8"L x 22 5/32"D. Shelving system is cantilevered and angle can be adjusted to maximize presentation
* Shelf supports a maximum weight of 150 lbs
* Cabinet holds (16) 18"L x 26"D display pans. Pans supplied by others
* Case is equipped with 4 light sources for maximum product display; (3) shelf mounted and (1) cabinet mounted
* Special brown bulb lighting provides balanced color spectrum that enhances the appearance of bakery products
* Safety shielded lighting tube assure longer, brighter, shadow-free product illumination
