Huck 352 gun riveter pulls magnagrip & C6 bolts
HUCK 352 GUN RIVETER PULLS MAGNAGRIP & C6 BOLTS
Huck 352 rivet gun in very good working condition. Pulls Magnagrip Huckbolts as used for Peterbuilt cab panels, truck trailer repair and industrial assembly work. Manual Included. Pulling for is also sufficent to shear 1/4" C6 steel Huckbolts.
* Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 lbs
* Overall Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-3/4 in.
* Overall Width, without nose . . . . . . . . . . . . . . . . . . . . . .6-3/8 in.
* Stroke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9/16 in.
The Model 352 Huck Installation Tool is a pneumatic single-action tool for high speed installation of Huckbolt Fasteners and Huck Blind Fasteners.
The rectangular-shaped handle is rigidly attached to the adapter, which, in turn is bolted to the cylinder. The spindle and nose assembly, located in the top of the handle, install the Huckbolt Fasteners. Inside the handle is mounted the spindle-operating lever with its antifriction roller, the upper ladder bearing cage and lower bearing on which the wedge rides, and the wedge and piston rod assembly that reciprocates between them tooperate the spindle. The spindle lever, therefore, is the connecting link between the wedge and piston rod and the spindle, which is located in the spindle housing. The lower end of the spindle lever rides in the milled slot of the wedge while the upper end straddles the flats on the spindle. During the working cycle, the wedge and piston rod move forward, pulling the lower end of the pivoted spindle lever forward. This forces the upper end of the spindle lever back, bringing the spindle and nose assembly parts back with it to install the fastener. The complete operating cycle of the tool is accomplished.
I am a Tool Hound and am always finding unique and different tools you never even knew you needed... so, You may be interested in our other listings.
Refurbished to good working condition.
