17" swg 42" cc kingston hj-1100 engine lathe, inch/metr
17" Swg 42" cc Kingston HJ-1100 ENGINE LATHE, Inch/Metr
17" Swing 42" Centers Kingston HJ-1100 ENGINE LATHE, Inch/Metric,Gap,DRO,3&4Jaw,(2) Steadies,Toolp
17"/24" x 40" KINGSTON BED ENGINE LATHE
MODEL: HJ1100, S/N: CH99114, NEW: 2000
SWING OVER BEDWAYS ................... 17"
SWING IN REMOVEABLE GAP .............. 24"
SWING OVER CROSS SLIDE ............... 10-9/16"
HOLE THRU SPINDLE .................... 2-1/4"
DISTANCE BETWEEN CENTERS ............. 43-1/2"
SPINDLE NOSE ......................... D1-6" CAMLOCK
SPINDLE SPEED RANGE (12) ............. 35 - 1350 RPM
ENGLISH THREADING RANGE (42) ......... 2 - 72 TPI
METRIC THREADING RANGE (39) .......... .2 - 14 mm
LONGITUDINAL FEED RANGE .............. .0012" - .034" IPR
CROSS FEED RANGE ..................... .0008" - .023" IPR
TAILSTOCK SPINDLE TAPER .............. #4MT
TAILSTOCK SPINDLE TRAVEL ............. 5-7/8"
APPROX FLOOR SPACE ................... 98"L x 41"W x 52"H
APPROX WEIGHT ........................ 3,250 LBS
MITUTOYO TWO AXIS DIGITAL READOUT
LIVE & DEAD CENTER FOR TAILSTOCK
Video: http:// /watch?v=LnPssQLY7Zk
